Van chặn thép rèn mặt bích

Pressure Cấp áp suất

Specification (NPS)

1/4

3/8

1/2

3/4

1

1^1/4

1^1/2

2

CL150-300-600

Face to face

CL150

CL300

CL600

L(RF)

L1(BW)

-

-

108

117

127

140

165

203

-

-

152

152

165

178

190

267

-

-

165

190

216

229

241

292

Handwheel Diameter W

-

-

100

100

125

160

160

180

Height

CL150

CL300

CL600

H

-

-

180

184

217

226

250

300

-

-

164

164

196

226

250

300

Height (angle dinmesion)   d

-

-

9

13

17.5

23

30

35

Pressure Cấp áp suất

Specification (NPS)

1/4

3/8

1/2

3/4

1

1^1/4

1^1/2

2

CL900-CL1500

Face to Face

L(RF), L1(BW)

-

-

216

229

254

279

305

368

-

-

216

229

254

279

305

371

Handwheel Diameter

W

-

-

125

160

160

-

200

200

Height

H

-

-

207

192

219

257

296

355

Height(angle dinmension)

d

-

-

12

15

20

28

32

40

Pressure Cấp áp suất

Specification (NPS)

1/4

3/8

1/2

3/4

1

1^1/4

1^1/2

2

CL2500

Face to Face

L(RF), L1(BW)

-

-

264

273

308

-

384

451

-

-

264

373

308

-

387

454

Handwheel Diameter

W

-

-

125

160

160

-

200

240

Height

H

-

-

207

240

258

-

355

300

Height(angle dinmension)

d

-

-

11

14

19

-

28

35

Pressure Cấp áp suất

Specification (NPS)

1/4

3/8

1/2

3/4

1

1^1/4

1^1/2

2

CL2500

Face to Face

L(RF), L1(BW)

-

-

264

273

308

329

384

451

-

-

264

373

308

349

387

454

Handwheel Diameter

W

-

-

200

200

280

280

200

300

Height

H

-

-

320

320

320

330

355

490

Height(angle dinmension)

d

-

-

11

14

19

25

28

35
